KÜHLMOBIL 1,2 kW to 2,9 kW
Compact and quiet - the ideal laboratory cooler
A powerful, yet quiet, small recirculating cooler that is available in different performance levels.
A cooling unit cools the circulating water or antifreeze mixture in a small container, from which it is extracted by a circulation pump and transported to the unit to be cooled. The 15 or 25 litre container is easily accessible and can be filled under the hinged lid on the top of the appliance.
This device type is available as a version with a 3.5 or 4.5 bar pump and an output of up to 10 or 40 l/min. Higher pump pressures and other temperature ranges are also possible as an option. This appliance type can also be supplied as an air-cooled or water-cooled version.
The air inlet is located at the front, the air outlet at the rear.
If flow indicators are required as an option, these are always installed in the last position in the return. Even with bypass control, the number of litres per minute actually flowing through the unit to be cooled can be read off. The digital form of a flow display is also available and can be read on the front at the touch of a button.
You can find a wide range of options and accessories for these appliance types in our options and accessories list. Or simply let us advise you!
We can also modify your devices for specific applications on request.
Application examples
- Rotary evaporator
- Water baths
- Calorimetry
- TGA
- Electron microscopy
- AAS
- ICP
- Extractions
- Instrumental cooling
- Fish tanks
- Laser
- Spraying systems
Functions & advantages
- Tap water savings 100 %
- No waste water costs
- Cooling water temperature, pressure, and flow rate are adjustable
- Consistent water quality, no limescale, no algae
- Compact tank with 15/25 litre capacity
- Relatively quiet
- Temperature indication via O-LED display with capacitive control panel
- On wheels
- Audible and visual alarm
- Suitable for an ambient temperature of up to 32° C
- Quick couplings with 9 mm hose nozzles
- Higher pump pressures also possible as well as extensive options and accessories
- Power control via microprocessor-controlled proportional control possible, resulting in high temperature constancy of the water supply temperature (0.1 K)
- All appliance types switch off completely in the event of a fault or malfunction.
Technical data KÜHLMOBIL 1.2 to 1.9 kW
| Technical data | KÜHLMOBIL 1,2 kW | KÜHLMOBIL 1,5 kW | KÜHLMOBIL 1,9 kW |
|---|---|---|---|
| Article designation (air-cooled version) | 010-A-RB400 | 101-A-RB400 | 111-A-RB400 |
| Article number | 1-100011 | 1-100012 | 1-100200 |
| Article designation (water-cooled version) | 010-W-RB400 | 101-W-RB400 | 111-W-RB400 |
| Article number | 2-100280 | 2-100281 | 2-100282 |
| Temperature range | 16-22 °C | 16-22 °C | 16-22 °C |
| Cooling capacity @ 20 °C | 1200 watts | 1500 watts | 1900 watts |
| Pump capacity max. 3.5 bar Pumpe | 10 l/min. | 10 l/min. | 10 l/min. |
| Dimensions W x D x H | 470 x 560 x 690 mm | 470 x 560 x 690 mm |
530 x 580 x 750 mm (A) 470 x 560 x 690 mm (W) |
| Power supply | 230 V/50 Hz/1 PH | 230 V/50 Hz/1 PH | 230 V/50 Hz/1 PH |
| Weight | 70 kg | 72 kg | 79 kg |
| Refrigerant | R134a | R134a | R134a |
Technical data KÜHLMOBIL 2.1 to 2.9 kW
| Technical data | KÜHLMOBIL 2,1 kW | KÜHLMOBIL 2,4 kW | KÜHLMOBIL 2,9 kW |
|---|---|---|---|
| Article designation (air-cooled version) | 121-A-RB400 | 132-A-RB400 | 142-A-RB400 |
| Article number | 1-100014 | 1-100015 | 1-100309 |
| Article designation (water-cooled version) | 121-W-RB400 | 132-W-RB400 | 142-W-RB400 |
| Article number | 2-100283 | 2-100284 | 2-100285 |
| Temperature range | 16-22 °C | 16-22 °C | 16-22 °C |
| Cooling capacity @ 20 °C | 2100 watts | 2400 watts | 2900 watts |
| Pump capacity max. 3.5 / 4.5 bar Pump | 10 l/min. (3.5 bar) | 10 l/min. (3.5 bar) | 40 l/min. (4.5 bar) |
| Dimensions W x D x H |
530 x 580 x 750 mm (A) 470 x 560 x 690 mm (W) |
530 x 580 x 750 mm (A) 470 x 560 x 690 mm (W) |
580 x 660 x 820 mm |
| Power supply | 230 V/50 Hz/1 PH | 230 V/50 Hz/1 PH | 230 V/50 Hz/1 PH |
| Weight | 81 kg | 82 kg | 95 kg |
| Refrigerant | R134a | R134a | R134a |
